The Intel Core i7-14700K is a 14th Gen desktop processor with 20 cores (8 Performance-cores and 12 Efficient-cores), 28 threads and a max turbo frequency of 5.6 GHz. It suits gamers, creators and workstation builders on the LGA1700 socket who want high multi-core performance plus built-in Intel UHD Graphics 770.
| Processor number | i7-14700K |
| Ordering code | BX8071514700K |
| Product collection | Intel Core i7 Processors (14th gen), formerly Raptor Lake |
| Vertical segment | Desktop |
| Lithography | Intel 7 |
| Total cores / threads | 20 (8P + 12E) / 28 |
| Max turbo frequency | 5.6 GHz |
| P-core max turbo / base | 5.5 GHz / 3.4 GHz |
| E-core max turbo / base | 4.3 GHz / 2.5 GHz |
| Cache | 33 MB Intel Smart Cache; 28 MB total L2 |
| Processor base power / max turbo power | 125 W / 253 W |
| Memory types | Up to DDR5 5600 MT/s; up to DDR4 3200 MT/s |
| Max memory / channels | 192 GB / 2 |
| ECC memory supported | Yes |
| Processor graphics | Intel UHD Graphics 770 (300 MHz base, 1.6 GHz max) |
| Graphics output / displays | eDP 1.4b, DP 1.4a, HDMI 2.1 / 4 displays |
| PCI Express | 5.0 and 4.0, up to 20 lanes (1x16+4 or 2x8+4) |
| Socket | FCLGA1700 |
| Max operating temperature (TJUNCTION) | 100 °C |
| Package size | 45.0 x 37.5 mm |
Suited to: high-end gaming, streaming, video editing and workstation builds that benefit from 20 cores and 28 threads.
Not suited to: motherboards with AMD or other non-LGA1700 sockets, or compact, low-power builds. For a 65 W base power option, see the Intel Core i7-13700, or browse all Intel processors.
It uses the FCLGA1700 socket. Check your motherboard's CPU support list and update the BIOS if needed.
It has 20 cores (8 Performance-cores and 12 Efficient-cores) and 28 threads.
Yes, it has Intel UHD Graphics 770, supporting up to 4 displays and up to 7680 x 4320 at 60Hz over DisplayPort.
Its processor base power is 125 W and its maximum turbo power is 253 W, so choose a cooler and power supply to suit.
