Gigabyte GeForce RTX 5060 Ti EAGLE MAX OC 8G GDDR7 Graphics Card

$1,091.11

The Gigabyte GeForce RTX 5060 Ti EAGLE MAX OC 8G graphics card pairs NVIDIA's Blackwell-based RTX 5060 Ti GPU with 8GB of GDDR7 memory and a factory overclock to 2617 MHz. It suits gamers and creators upgrading a desktop PC who want DLSS 5, ray tracing and up to four displays from one card.

Key features

  • Factory overclock: a 2617 MHz core clock, up from 2572 MHz on the reference card, gives extra performance out of the box.
  • 8GB GDDR7 memory: 28 Gbps memory on a 128-bit bus feeds the GPU's 4608 CUDA cores.
  • WINDFORCE cooling: Hawk fans with alternate spinning, a copper plate, composite copper heat pipes and server-grade thermal gel on the VRAM and MOSFETs keep temperatures in check, and the fans stop at low load for quieter light use.
  • Four-display output: 3 x DisplayPort 2.1b and 1 x HDMI 2.1b, with digital resolution up to 7680 x 4320.
  • Reinforced backplate: a bent-edge backplate fastened to the I/O bracket adds structural rigidity.

Specifications

Model (MPN) GV-N506TEAGLEMAX OC-8GD
Graphics processing NVIDIA GeForce RTX 5060 Ti (Blackwell architecture)
Core clock 2617 MHz (reference card: 2572 MHz)
CUDA cores 4608
Memory 8GB GDDR7, 128-bit
Memory clock 28 Gbps
Card bus PCI-E 5.0
Outputs 3 x DisplayPort 2.1b, 1 x HDMI 2.1b
Maximum digital resolution 7680 x 4320
Multi-view 4 displays
Card size L 281 x W 115 x H 40 mm
PCB form ATX
DirectX / OpenGL DirectX 12 API / OpenGL 4.6
Recommended PSU 650W
Power connectors 1 x 8-pin
In the box Graphics card, quick guide

Compatibility

  • System type: desktop PCs only. Gigabyte states its graphics cards (other than its Mining Series) are intended for desktop PC use.
  • Motherboard: a PCI Express graphics slot. The card uses a PCI-E 5.0 interface, matched by boards such as the Gigabyte B760M GAMING X WIFI6E GEN5 motherboard.
  • Power supply: 650W recommended, with one 8-pin power connector.
  • Case clearance: room for a 281 mm long, 115 mm wide and 40 mm high card.

Who it's for

Suited to: desktop gamers and content creators who want RTX 50 Series features such as DLSS 5, NVIDIA Reflex and NVIDIA Studio tools, and anyone running up to four monitors.

Not suited to: laptops, cases with less than 281 mm of graphics card clearance, systems with a power supply under 650W, or cryptocurrency mining, which Gigabyte says voids the warranty. If you need more video memory, look at the Gigabyte RTX 5060 Ti EAGLE MAX OC 16G version with 16GB of GDDR7, or browse more Gigabyte graphics cards, motherboards and PC components.

FAQs

How much memory does the RTX 5060 Ti EAGLE MAX OC 8G have?

It has 8GB of GDDR7 memory on a 128-bit bus, running at 28 Gbps. The 16G version of this card has 16GB.

What power supply do I need?

Gigabyte recommends a 650W power supply. The card uses a single 8-pin power connector.

Will it fit in my PC case?

It fits if your case has room for a card 281 mm long, 115 mm wide and 40 mm high. Check your case's maximum graphics card length before buying.

How many monitors can I connect?

You can connect up to four monitors using its 3 DisplayPort 2.1b outputs and 1 HDMI 2.1b output, at up to 7680 x 4320 digital resolution.
