APC Schneider OffGrid Power Station 500, 517Wh, 230V PPS500-AZ
The Schneider OffGrid Portable Power Station 500 (APC PPS500-AZ) is a 517Wh lithium-ion power station with 2 Australian AS3112 pure sine wave outlets, USB-A, USB-C and wireless charging. It suits camping, caravanning, worksites and home backup, where you need quiet 230V power for laptops, phones, lights or small appliances away from a power point.
Key features
- 517Wh capacity, 500W rated (1000W peak): enough to run devices such as a 60W CPAP for about 7 hours, according to Schneider Electric's estimates.
- 2 Australian AS3112 outlets with pure sine wave output: plug in standard Australian appliances, with clean power that helps protect sensitive electronics.
- Charge many devices at once: 3 USB-A, 2 USB-C (including USB-C PD up to 60W), 2 DC5521 outputs, a 12V car outlet and a 15W wireless charging pad.
- 3 ways to recharge: from a wall outlet, a car outlet or an optional Schneider OffGrid solar panel (up to 200W solar input), while still powering your devices.
- LCD display and LED light: check charge level and runtime at a glance, with a 3-mode light including SOS.
Specifications
| Model | PPS500-AZ |
| Battery | Lithium-ion (LG cells), 517Wh |
| Cycle life | 500+ cycles to 80% capacity |
| AC output | 230V, 50Hz, pure sine wave; 500W rated, 1000W peak |
| AC outlets | 2 x AS3112 (Australian) |
| Maximum combined output | 749W (AC, DC, USB and wireless) |
| USB-A | 3 x 5V 2.4A |
| USB-C | 2 ports, including USB-C PD up to 60W |
| DC outputs | 2 x DC5521; 1 x 12V car outlet (with dust cover) |
| Wireless charging | Up to 15W |
| AC charging input | 190–265V, 50/60Hz |
| DC / solar input | DC7909, 12–30V DC, 10A, 200W max |
| Compatible solar panels | Schneider OffGrid PSP100 (100W) or PSP200 (200W), sold separately |
| Display / light | LCD; LED light with 3 modes including SOS |
| Dimensions (H x W x D) | 204 x 200 x 250 mm |
| Weight | 5.5 kg |
| Operating temperature | Charging 0 to 40°C; discharging -10 to 40°C |
| Casing | 60% post-consumer recycled plastic |
| In the box | Power station, AC charging cable, car charging cable, safety guide, quick installation guide |
| Manufacturer warranty | 2 years |
Who it's for
Suited to: campers, caravanners, tradespeople and households that want portable 230V power for phones, laptops, cameras, lights, a CPAP or a small fridge, and the option to recharge from solar.
Not suited to: appliances that draw more than 500W continuously, such as kettles or heaters. For more capacity, see the Schneider OffGrid Portable Power Station 730 (PPS730-AZ).
FAQs
How long will the PPS500-AZ run my devices?
It depends on what you plug in. Schneider Electric estimates about 32 phone recharges, 15 tablet recharges, 35 hours of lamp use, or 7 hours of a mini fridge or a 60W CPAP from a full charge.
Can I charge it with solar panels?
Yes. It accepts up to 200W of solar input (12–30V DC), and Schneider Electric recommends its PSP100 or PSP200 panels, such as the Schneider OffGrid 100W portable solar panel (PSP100).
Does it have Australian power outlets?
Yes. The PPS500-AZ is the Australian model, with 2 AS3112 outlets delivering 230V pure sine wave power.
What warranty does it have?
Schneider Electric provides a 2-year warranty. The user manual asks you to register the product at warranty.apc.com within 10 days of purchase.
