The ASUS ROG Strix X870-F Gaming WiFi is an AM5 ATX motherboard for AMD Ryzen 9000, 8000 and 7000 Series desktop processors, built for high-end gaming and creator PCs. It pairs PCIe 5.0 graphics and storage with dual USB4 ports, Wi-Fi 7 and Intel 2.5Gb Ethernet.
| Model | ROG STRIX X870-F GAMING WIFI |
| Socket / CPU support | AM5; AMD Ryzen 9000, 8000 and 7000 Series desktop processors |
| Chipset | AMD X870 |
| Memory | 4 x DDR5 DIMM, up to 256GB, dual channel; up to 8000+ MT/s (OC); ECC and non-ECC unbuffered; AMD EXPO |
| Graphics outputs | 1 x DisplayPort 1.4, 1 x HDMI 2.1, 2 x USB4 Type-C with DP Alt mode (depends on CPU graphics) |
| Expansion slots | 1 x PCIe 5.0 x16 (Ryzen 9000/7000; PCIe 4.0 x8/x4 with Ryzen 8000), 1 x PCIe 4.0 x16 slot (x4 mode, chipset) |
| Storage | 4 x M.2 (2 x PCIe 5.0 x4 from CPU with Ryzen 9000/7000, 2 x PCIe 4.0 x4 from chipset), 2 x SATA 6Gb/s |
| RAID | PCIe RAID 0/1/5/10 (RAID 5 with Ryzen 9000 only), SATA RAID 0/1 |
| Ethernet | Intel 2.5Gb Ethernet, ASUS LANGuard |
| Wireless | Wi-Fi 7 (802.11be) 2x2, 2.4/5/6GHz, up to 320MHz; Bluetooth v5.4 (may vary by module) |
| Rear USB | 2 x USB4 40Gbps Type-C, 6 x USB 10Gbps (5 x Type-A, 1 x Type-C up to 30W PD), 4 x USB 5Gbps Type-A |
| Front USB | 1 x USB 20Gbps Type-C connector, 2 x USB 5Gbps headers (4 ports), 2 x USB 2.0 headers (4 ports) |
| Audio | ROG SupremeFX 7.1 (ALC4080) with Savitech SV3H712 amplifier, optical S/PDIF out |
| Fan headers | CPU, CPU OPT, AIO pump and 5 x chassis (all 4-pin) |
| Lighting | 3 x addressable Gen 2 headers, Aura Sync |
| DIY features | BIOS FlashBack and Clear CMOS buttons, pre-mounted I/O shield, Q-Antenna, Q-DIMM, Q-LED, SafeSlot, SafeDIMM |
| Form factor | ATX, 30.5 x 24.4 cm |
| BIOS | 256Mb flash ROM, UEFI AMI BIOS |
| Operating system | Windows 11 |
| In the box | 2 x SATA 6Gb/s cables, thermal pad for M.2 22110, ASUS WiFi Q-Antenna, cable ties, M.2 Q-Latch and Q-Slide packages, 4 x M.2 rubber packages, ROG key chain, ROG Strix stickers, quick start guide |
Supports AMD Ryzen 9000, 8000 and 7000 Series desktop processors on the AM5 socket, such as the AMD Ryzen 7 9800X3D or AMD Ryzen 7 7700; see ASUS’s CPU support list for the full list. With Ryzen 8000 CPUs, the top x16 slot runs at PCIe 4.0 x8/x4 and M.2_2 is not supported. Requires DDR5 memory. Full Wi-Fi 7 support on Windows 11 needs version 24H2 or later.
Suited to: gamers, streamers and creators building a new AM5 PC who want PCIe 5.0, fast USB4 and Wi-Fi 7 on a full-size ATX board.
Not suited to: small-form-factor (mATX or ITX) cases, or builds needing many SATA drives (2 SATA ports). For more SATA ports and 5 M.2 slots, see the ASUS ROG Strix X870E-E Gaming WiFi, or browse more ASUS products.
It supports AMD Ryzen 9000, 8000 and 7000 Series desktop processors on the AM5 socket.
Up to 256GB of DDR5 across four DIMM slots, with overclocked speeds of 8000+ MT/s.
Yes. It has Wi-Fi 7 (802.11be, 2x2) and Bluetooth v5.4, plus an Intel 2.5Gb Ethernet port.
Four M.2 slots: two PCIe 5.0 x4 (with Ryzen 9000/7000) and two PCIe 4.0 x4 from the chipset.
